SIP 20" Heavy-Duty Orbital Floor Fan

05635

SIP 20" Heavy-Duty Orbital Floor FanSIP 20" Heavy-Duty Orbital Floor FanSIP 20" Heavy-Duty Orbital Floor FanSIP 20" Heavy-Duty Orbital Floor FanSIP 20" Heavy-Duty Orbital Floor FanSIP 20" Heavy-Duty Orbital Floor FanSIP 20" Heavy-Duty Orbital Floor Fan
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.

The SIP 20" Heavy-Duty Orbital Floor Fan delivers powerful multi-directional airflow to help cool spaces and circulate air in a variety of indoor environments.

Mounted at four points on a steel tube frame, this heavy-duty 3-blade fan can be rotated and fixed between 720° on both its horizontal and vertical axis. This creates an orbital effect which maximises airflow coverage.

Fans are essential in helping to provide improved air quality to indoor spaces.

KEY FEATURES

  •  Powerful airflow via heavy-duty 3-blade fan
  •  Variable speed settings up to max. 1300rpm
  •  Orbital airflow function with 720° coverage
  •  Sturdy and compact design allows easy movement
  •  Solid mesh steel guarding for greater safety

SIP 2-Year Standard Silver Warranty | Find out more

Full Specification

The SIP 20" Heavy-Duty Orbital Floor Fan delivers powerful multi-directional airflow to help cool spaces and circulate air in a variety of indoor environments.

Mounted at four points on a steel tube frame, this heavy-duty 3-blade fan can be rotated and fixed between 720° on both its horizontal and vertical axis. This creates an orbital effect which maximises airflow coverage.

Fans are essential in helping to provide improved air quality to indoor spaces.

Applications & uses: Delivers powerful variable speed air circulation to indoor spaces. Perfect for industrial, commercial and agricultural workshop areas.

SIP 2-Year Standard Silver Warranty | Find out more

Powerful airflow
A heavy-duty 3-blade fan is powered from a 120w motor to deliver powerful and consistent airflow coverage.

Variable speed settings
Three settings for variable fan speed:

  • Low: 900rpm
  • Medium: 1100rpm
  • High: 1300rpm

Orbital airflow function
The manually adjustable fan head can rotate 360° on its horizontal axis and 360° on its vertical axis to create 720° coverage of air circulation. The orbital effect created maximises airflow coverage for greater ventilation.

Outstanding mobility
A sturdy and compact design allows the fan to be easily moved between locations for use.

Enhanced safety features
Fan blades are fully enclosed with solid mesh steel guarding for greater user safety.
A robust and balanced steel frame maintains fan stability when in use.

Technical Information

ITEM NO. 05635
Input Supply: 230v (13A)
Motor Power: 120w (0.16hp)
Power Cable: 180cm
Fan Diameter: ⌀ 20" (508mm)
Speed Settings: 3 speed settings
Low Medium High
900rpm 1100rpm 1300rpm
Noise Level: 68dB(A)
Net Weight: 6.40kg
Gross Weight: 7.80kg
Product Dimensions: 695(H) x 665(W) x 258mm(D)
Packaged Dimensions: 765(H) x 710(W) x 270mm(D)

Documentation

PRODUCT DOCUMENTATION

Click below to access any documentation currently available for this product.

DOWNLOAD HERE

Warranty Information



COMES WITH A 2 YEAR STANDARD WARRANTY*

NOW AVAILABLE ON ALL SIP MACHINES!

SIP products offer exceptional durability, reliability, and heavy-duty performance. All of our machines are underpinned by the SIP 2-Year Standard Silver Warranty*. In addition to this, we offer a service-based Gold Warranty that extends your cover for a further 2 years when purchased.

All SIP Premium Partner Brands offer comprehensive warranties of their own!

*Excludes accessories and consumables.
